Pasipriešinimo matavimo dėžutė 1 kW



Informacija apie prekę Prekės kodas 1002733 [U11183] Svoris 0.25 kg Išmatavimai 7.2 x 7.2 x 9 cm Ženklas Chauvin Arnoux Metrix

Resistance Decade 1 kOhm

Resistance decades which can be mechanically connected to one another, e.g. in order to assemble a Wheatstone bridge. With color-coded safety sockets and control knob for setting measurement resistances in 10 steps. Includes 25-cm safety patch cord.

Connections: via 4-mm-safety sockets
Dimensions: 72 mm x 72 mm x 90 mm
Weight: 220 g

Measurement range: 100 Ohm up to 1 kOhm
Step size: 100 Ohm
Max. current: 75 mA
Accuracy: 0.5%
